Gridly: The AI Full-Stack Developer

Gridly is an AI-powered, full-stack application builder that turns natural language prompts into deployable code. It provides a multi-modal interface where you can generate, test, and integrate a complete frontend and backend, all from one dashboard.

At its core, Gridly uses a suite of Google Generative AI models (Gemini 2.5 Flash, Gemini 2.5 Pro, and Imagen 3) to act as your co-pilot.

🎥 Watch the demo video on YouTube:

---

Key Features

• AI-Powered Component Generation: Describe a UI element and Gridly generates a responsive React component with Tailwind CSS.
• On-the-Fly Image Generation: Ask for a visual asset and Gridly uses Imagen 3 to generate and embed it directly into your components.
• AI-Powered Backend Generation: Describe API logic and Gridly generates the Node.js/Express.js code for it.
• In-Browser Virtual Server: Test your generated backend endpoints instantly using a built-in API tester, powered by a virtual Express server running in your browser.
• Automatic Full-Stack Integration: The "Merged" view uses Gemini 2.5 Pro to analyze your frontend and backend, then automatically rewrites your React components to fetch data from your new API.
• Full Project Export: Download a clean, runnable, full-stack project (Vite + Express) with all AI-generated test harnesses replaced by standard fetch calls.
• Visual Grid Layout: Drag, drop, and resize your components on a responsive 24-column grid.
• Persistent State: Components, API endpoints, and virtual database state are saved locally so you can pick up where you left off.

How It Works: The Three Modes

Gridly operates in three distinct modes:

1. Frontend Mode

Your visual canvas. Use the chat bar to describe UI components, and Gemini 2.5 Flash generates the React/Tailwind code. You can draw boxes on the grid to place components, edit their code live, and even generate images using Imagen 3 which are saved locally.

2. Backend Mode

Your server logic center. Describe API endpoints (e.g., POST /api/login) to generate Express.js routes. You can also "Auto-Generate" endpoints based on your frontend components. All routes run in a local Virtual Server with a persistent in-memory database.

3. Merged Mode

The integration hub. Gemini 2.5 Pro analyzes your entire grid and API list, then intelligently rewrites your frontend components to use the live backend endpoints, providing a fully functional preview of your merged application.

Tech Stack

• Frontend: React 19 (Vite), Tailwind CSS
• Layout: react-grid-layout
• AI: Google Gemini 2.5 Flash & Pro, Imagen 3
• Backend Simulation: Custom in-browser Virtual Express Server
• Storage: localStorage & IndexedDB

Getting Started

Prerequisites

• Node.js (v18+)
• A Google AI API Key (with access to Gemini and Imagen)

Installation

1. Clone the repository:

   git clone https://github.com/cnowdev/gridly.git
   cd gridly

2. Install dependencies:

   npm install

3. Set up environment variables: Create a .env file in the root and add your API key:

   VITE_API_KEY=YOUR_GOOGLE_AI_API_KEY_HERE


4. Run the application:

   npm run dev
