⚡ Real-Time Voice Agent – <3 s Round-Trip

Mic ▶ Deepgram Nova-3 (STT) ▶ GPT-4o-mini (LLM) ▶ Deepgram Aura-2 (TTS) ▶ Speaker

Goal: Keep the 95-th percentile end-to-end latency below 3 second – from the moment a user finishes speaking until the first audio sample of the assistant’s reply is heard.

---

✨ Features

Component	Target P95	How we hit it
STT	≤ 300 ms	48 kHz WebSocket + endpointing=200
LLM	≤ 200 ms (first token)	GPT-4o-mini, streaming, max 60 tokens
TTS	≤ 250 ms TTFB	Aura-2 WebSocket, 20-char micro-batches
Playback watchdog	100–250 ms	Queue-drain + silence detection

• Full-duplex – mic continues in the background (optionally even while Aura speaks).
• Live RTT metric – every turn is timed and printed (⏱ End-to-end RTT: xxx ms).
• No SDK lock-in – pure WebSockets, <300 LOC of Python.

---

📦 Requirements

• Python ≥ 3.9
• PortAudio / PyAudio (for mic and playback)
• A Deepgram API key with Nova-3 and Aura-2 access
• An OpenAI API key (GPT-4o-mini)

python -m venv .venv && source .venv/bin/activate
pip install -r requirements.txt

🔧 Configuration

Create a .env next to the script:

DEEPGRAM_API_KEY=...
OPENAI_API_KEY=sk-...

Optional tweaks (inside the script):

Constant	Default	Notes
RATE	48000	Use 16000 for lower bandwidth
CHUNK	8000	Audio frames sent per WS message (~42 ms)
SEND_EVERY	180	Characters before we flush to Aura
ALLOW_INTERRUPT	False	Set True to capture mic during TTS

---

▶ Running

python realtime_voice_agent.py

CLI output (example):

🔗  Mic → Nova-3 → GPT-4o → Aura-2 – starting …
[ 0.16s] 🎙  Mic streaming …  Ctrl-C to stop
[ 1.20s] 🟢 STT WebSocket open
[ 1.31s] 🟢 TTS WebSocket open
[ 4.85s] 📝 User: Hi, what can you do?
[ 5.33s] ⚡ GPT first token 484 ms
[ 5.58s] 🎧 Aura audio started
[ 5.81s] 🌊 Aura finishing playback...
[ 5.81s] ⏱  End-to-end RTT: 962 ms
[ 5.81s] 🎤  You can speak now …

---

🛠 How it works

1. Microphone → STT
   PyAudio captures 48 kHz 16-bit mono PCM. Every 42 ms we push a frame to Deepgram’s /listen WS.

2. STT → LLM
   When is_final=true is received, we drop the transcript into an async queue for GPT-4o.

3. LLM streaming
   GPT-4o streams tokens. Every ≈ 180 chars we send a {"type":"Speak","text":…} to Aura-2.

4. TTS → Speaker
   Aura responds with 48 kHz linear16 PCM chunks which we play immediately in a background thread.

5. Watch-dog ends playback when either PlaybackFinished arrives, the audio queue stays empty ≥ 100 ms, or 3 s of total silence elapse – then we print the RTT and cue the user.

---

🧪 Benchmarks

Test	RTT (mean)	Notes
Local MacBook M2 + AirPods	< 2100 ms	Wi-Fi, OpenAI/Deepgram
GCP e2-medium (us-central)	~3100 ms	Low-variance, wired

---

📚 Docs & Links

• Deepgram live STT: https://developers.deepgram.com/reference/speech-to-text-api/listen-streaming

• Deepgram Aura-2 TTS: https://developers.deepgram.com/reference/text-to-speech-api/speak-streaming

• OpenAI Chat completions (stream): https://platform.openai.com/docs/guides/text-generation

---

🤝 Contributing

PRs welcome! Open an issue if you spot latency regressions.
